Lentes Esféricas, Singlete Y Plano-Convexas (PCX)

Plano-Convex Lenses are Optical Lenses with a positive focal length. Plano-Convex Lenses are ideal for light collimation or for focusing applications utilizing monochromatic illumination, in a range of industries including industrial, pharmaceutical, robotics, or defense. PCX Lenses have one convex surface. For maximum efficiency, the second, plano (flat) surface should face the desired focal plane. Plano-Convex lenses are commonly used in a wide range of applications or industries.

Edmund Optics offers the world’s largest inventory of off-the-shelf optical components, which includes a large variety of Plano-Convex Lenses. Edmund Optics’ PCX lenses are available in a range of coating or substrate options. Anti-reflection coatings range from the Ultraviolet (UV) to the Infrared (IR), including UV-AR, UV-VIS, MgF₂, VIS 0°, VIS-NIR, NIR I, NIR II, or Telecom-NIR. Additional coatings designed specifically for laser wavelengths, such as 266nm, 355nm, 532nm, or 1064nm are also offered. Germanium (Ge), Silicon (Si), or Zinc Selenide (ZnSe) substrates are ideal for Infrared (IR) applications.

Lentes Plano-Convex (PCX)

Wavelength Range of 350-2200nm
Precision Diameter and Centration Tolerances Allow for Easy OEM Integration
Wide Variety of Diameters, Focal Lengths, and Coatings
Anti-Reflection Coating Options: MgF₂, VIS 0°, VIS-NIR, NIR I, NIR II, VIS-EXT, and YAG-BBAR

Lentes PCX con Tratamiento MgF₂

AR Coated to Provide <1.75% Reflectance per Surface for 400 - 700nm
Designed for 0° Angle of Incidence
Various Coating Options: Uncoated, VIS 0°, VIS-NIR, NIR I, NIR II, VIS-EXT, and YAG-BBAR

Lentes PCX con Tratamiento VIS 0°

Tratamiento AR para Proporcionar <0.4% de Reflejo por Superficie de 425nm a 675nm
Diseñados Para Un Ángulo de Incidencia de 0°

Lentes PCX con Tratamiento NIR-I

AR Coated to Provide <0.5% Reflectance per Surface for 600 - 1050nm
Designed for 0° Angle of Incidence
Various Coating Options: Uncoated, MgF₂, VIS 0°, VIS-NIR, NIR II, VIS-EXT, and YAG-BBAR

NIR II Coated Plano-Convex (PCX) Lenses

AR Coated to Provide <0.7% Reflectance per Surface for 750 - 1550nm
Designed for 0° Angle of Incidence
Various Coating Options: Uncoated, MgF₂, VIS 0°, VIS-NIR, NIR I, VIS-EXT, and YAG-BBAR

VIS-EXT Coated Plano-Convex (PCX) Lenses

Visible Broadband Anti-Reflection Coating with Extended UV Performance
AR Coated to Provide <0.5% Reflectance per Surface for 350 - 700nm
Designed for 0° Angle of Incidence
Various Coating Options: Uncoated, MgF₂, VIS 0°, VIS-NIR, NIR I, NIR II, and YAG-BBAR

Lentes PCX Tratados con VIS-NIR

AR Coated to Provide <1.25% Reflectance per Surface for 400 - 1000nm
<0.25% Reflectance @ 880nm
Designed for 0° Angle of Incidence
Various Coating Options: Uncoated, MgF₂, VIS 0°, NIR I, NIR II, VIS-EXT, and YAG-BBAR

YAG-BBAR Coated Plano-Convex (PCX) Lenses

Optimized for R<0.25% @ Both 532nm and 1064nm
AR Coated to Provide <1.0% Reflectance per Surface for 500 - 1100nm
Designed for 0° Angle of Incidence
Various Coating Options: Uncoated, MgF₂, VIS 0°, VIS-NIR, NIR I, NIR II, and VIS-EXT

Micro Plano-Convex (PCX) Lenses

Diameters as Small as 1mm
Short Focal Lengths for Integration into Compact Devices
Broadband Antireflection Coating Options Available

Nuevo
Ultrafast Thin Plano-Convex (PCX) Lenses

Ultra-Thin Center Thickness to Limit GDD
IBS Broadband AR Coating with <0.1% Reflectance (Coming Soon)
Ideal for Ultrafast and Laser Optics Applications
UV or IR Grade Fused Silica Substrates

405nm Laser Line Coated Plano-Convex (PCX) Lenses

<0.25% Reflection at 405nm for Diode Applications
BBAR Coating Options Also Available: MgF₂, VIS 0°, VIS-NIR, NIR I, NIR II
405nm, 532nm, 633nm, 785nm, 980nm, 1064nm, 1310nm, and 1550nm V-Coated Options Offered

532nm Laser Line Coated Plano-Convex (PCX) Lenses

<0.25% Reflection at 532nm for 2nd Harmonic Nd:YAG Applications
BBAR Coating Options Also Available: MgF₂, VIS 0°, VIS-NIR, NIR I, NIR II
405nm, 532nm, 633nm, 785nm, 980nm, 1064nm, 1310nm, and 1550nm V-Coated Options Offered

633nm Laser Line Coated Plano-Convex (PCX) Lenses

<0.25% Reflection at 633nm for HeNe Applications
BBAR Coating Options Also Available: MgF₂, VIS 0°, VIS-NIR, NIR I, NIR II
405nm, 532nm, 633nm, 785nm, 980nm, 1064nm, 1310nm, and 1550nm V-Coated Options Offered

785nm Laser Line Coated Plano-Convex (PCX) Lenses

<0.25% Reflection at 785nm
BBAR Coating Options Also Available: MgF₂, VIS 0°, VIS-NIR, NIR I, NIR II
405nm, 532nm, 633nm, 785nm, 980nm, 1064nm, 1310nm, and 1550nm V-Coated Options Offered

1064nm Laser Line Coated Plano-Convex (PCX) Lenses

<0.25% Reflection at 1064nm for Fiber and Nd:YAG Applications
BBAR Coating Options Also Available: MgF₂, VIS 0°, VIS-NIR, NIR I, NIR II
405nm, 532nm, 633nm, 785nm, 980nm, 1064nm, 1310nm, and 1550nm V-Coated Options Offered

1550nm Laser Line Coated Plano-Convex (PCX) Lenses

<0.25% Reflection at Design Wavelength
Coatings Available for Diode, HeNe, and Nd:YAG Laser Sources
BBAR Coating Options Also Available: MgF₂, VIS 0°, VIS-NIR, NIR I, NIR II
405nm, 532nm, 633nm, 785nm, 980nm, 1064nm, 1310nm, and 1550nm V-Coated Options Offered

Lentes PCX de Silicona Fundida UV

Gamme de longueurs d'onde de 200 à 2200 nm
Tolérances de précision sur le diamètre et centrage pour une intégration OEM facilité
Nombreux diamètres, distances focales, et traitements disponibles

Lentes PCX de Sílice Fundida con Recubrimiento Para Uso con Láser de 405nm

Reflexión de <0.25% a 405 nm para diodos de 405 nm
Diámetros disponibles entre 5 y 50 mm
Disponible con una EFL entre 10 y 250 mm
Opciones de recubrimientos-V ofrecidos para532 nm, 633 nm, 1064 nm, and 1550 nm

Lentes PCX de Sílice Fundida con Recubrimiento Para Uso con Láser de 532nm

Reflexión de <0.25% a 532 nm para el 2º armnico en aplicaciones Nd:YAG
Diámetros disponibles entre 5 y 50 mm
Disponible con una EFL entre 10 y 250 mm
Opciones de recubrimientos-V ofrecidos para 405nm, 633nm, 1064nm, and 1550nm

Lentes PCX de Sílice Fundida con Recubrimiento Para Uso con Láser de 633nm

<0.25% Reflection at 633 nm for HeNe Applications
Diámetros disponibles entre 5 y 50 mm
Opciones de recubrimientos-V ofrecidos para 10 - 250 mm EFL Designs Available
405nm, 532nm, 1064nm, and 1550nm

Lentes PCX de Sílice Fundida con Recubrimiento Para Uso con Láser de 1064nm

Reflexión de <0.25% Reflection a 1064 nm para aplicaciones de fibra y Nd:YAG
Diámetros disponibles entre 5 y 50 mm
10 - 250 mm EFL Designs Available
Opciones de recubrimientos-V ofrecidos para 405nm, 532nm, 633nm, and 1550nm

Lentes PCX de Sílice Fundida con Recubrimiento Para Uso con Láser de 1550nm

Reflexión de <0.25% Reflection a 1550 nm
Diámetros disponibles entre 5 y 50 mm
Disponible con una EFL entre 10 y 250 mm
Opciones de recubrimientos-V ofrecidos para 405nm, 532nm, 633nm, and 1064nm

Laser Grade Plano-Convex (PCX) Lenses

Guaranteed Laser Damage Threshold
10-5 Surface Quality
λ/10 Surface Accuracy

λ/20 PCX Lenses

λ/20 Surface Accuracy
Available Uncoated or with a Variety of Nd:YAG Laser Coating Options
Includes Full Data Package with Interferogram and Measured Results for Geometric Tolerances

Large PCX Condenser Lenses

Large Sizes Available – 100 to 250mm Diameter
Polished Surfaces for Superior Precision vs. Cast Optics
Wavelength Range of 350-2200nm

Calcium Fluoride Plano-Convex (PCX) Lenses

Greater than 90% Transmission from 200nm - 7μm
Low Index of Refraction
Vacuum Grade UV Substrate

Nuevo
Zinc Selenide (ZnSe) Plano-Convex (PCX) Lenses

Edmund Optics® Designed, II-VI Manufactured
Premier Grade ZnSe Material
Uncoated or Broadband AR Coating Options

Germanium Plano-Convex (PCX) Lenses

Wavelength Range of 2 - 16μm
Rugged, Durable Material
Ideal for Defense, Security, and Thermal Imaging Applications
Additional Infrared Lenses Available in Popular Substrates

Silicon Plano-Convex (PCX) Lenses

Wavelength Range of 1.2 - 7μm
Low Density and Dispersion
Focal Lengths of 25 – 250mm Available
Additional Infrared Lenses Available in Popular Substrates

Lentes de Selenio de Zinc

Gama de Transmisión Usable es de 600nm Hasta 16μm
Dispersión Baja

Lentes Plano-Convexas (PCX) de Silicio

Baja densidad y dispersión
Transmisión de 1.2 a 7μm

Plano-Convex (PCX) and Simple Lens Kits

Simple Lens Kits Include PCX, DCX, PCV, and DCV Lenses
Kits Available for 12mm and 25mm Diameter Lenses
Uncoated or BBAR Coating Options

N-K5 Lenses

N-K5 Substrate
Various Anti-Reflection (AR) Coatings
PCX and DCX Options Available

Lentes PCX con Tratamiento Telecom-NIR

Distancia focal positiva
Micro lentes PCX para recoger y enfocar la luz
Acabados disponibles: Sin recubrimiento, MgF₂ y NIR I

980nm Laser Line Coated Plano-Convex (PCX) Lenses

<0.25% Reflection at 980nm
BBAR Coating Options Also Available: MgF₂, VIS 0°, VIS-NIR, NIR I, NIR II
405nm, 532nm, 633nm, 785nm, 980nm, 1064nm, 1310nm, and 1550nm V-Coated Options Offered

1310nm Laser Line Coated Plano-Convex (PCX) Lenses

<0.25% Reflection at Design Wavelength
Coatings Available for Diode, HeNe, and Nd:YAG Laser Sources
BBAR Coating Options Also Available: MgF₂, VIS 0°, VIS-NIR, NIR I, NIR II
405nm, 532nm, 633nm, 785nm, 980nm, 1064nm, 1310nm, and 1550nm V-Coated Options Offered
