Substrate:
Many glass manufacturers offer the same material characteristics under different trade names. Learn More
Crystal Quartz
Length (mm):
28.00
Surface Quality:
20-10
Type:
Linear Polarizer
Dimensional Tolerance (mm):
+0.0/-0.2
Construction:
Crystalline Rochon Polarizer
Transmitted Wavefront, P-V:
λ/4 @ 632.8nm
Length Tolerance (mm):
±0.1
Beam Deviation (arcmin):
<3
Housing:
Black Anodized Aluminum
Wavelength Range (nm):
200 - 2300
Damage Threshold, By Design:
Damage threshold for optical components varies by substrate material and coating. Click here to learn more about this specification.
Rochon Polarizers consist of two birefringent material prisms in optical contact with one another. The ordinary and extraordinary rays remain collinear through the first prism. Upon entering the second prism, the ordinary rays do not experience a change in the refractive index and pass through the prism without deviation, while the extraordinary rays refract at the interface.
